MS26482 Connector, MS3476W18-32S, MIL-C-26482Ⅱ, MS26482 SeriesⅡ

Name: MS26482 Connector MS3476W1832S MILC26482 MS26482 Series
Brand: HIGH WOOD
Price: 10 USD

Wholesale MS26482 Connector, MS3476W18-32S, MIL-C-26482Ⅱ, MS26482 SeriesⅡ from china suppliers

Brand Name : HIGH WOOD

Model Number : MS3476W18-32S

Certification : AS9001

Place of Origin : CHINA

MOQ : 100PCS

Price : 10＄-150＄

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100，000pcs per month

Delivery Time : 2-9weeks

Packaging Details : standard expect package

Operating temperature range : -55 ℃ ~ +200 ℃

Material : Aluminium-alloy, copper-alloy or stainless steel

Anti-RFI : At frequency 100 ~ 1000 MHz, leakage attenuation: 65~45dB.

Durability : ≥ 500 mating cycles

Shock : Max acceleration 294 m/s2

Random vibration : Frequency 10 Hz ~ 2000 Hz at 196 m/s2

Contact Now

MS3476W18-32S,MIL-C-26482Ⅱ,MS26482 seriesⅡ

MIL-C-26482 series II connector is the upgrade to MIL-C-26482 Series I. They are designed

as bayonet coupling, rear-removable crimp contact, medium contact density, mating hermetic

and RFI shielding.

This family of circular connectors is offered 3 kinds of material shell, 9 kinds of size shell,

4 kinds of finish, 2 plug styles, 4 receptacle-mounting styles, 3 kinds of contact and more

than 30 kinds of contact layout.

Widely used on commercial, military and aerospace systems, etc.

How to order.

	MS	3474	W	18	-06	P	N
Basic series
Type of shell 3470 = Narrow flange receptacle 3471 = Cable connecting receptacle 3472 = Wide flange receptacle 3474 = Jam nut receptacle 3475 = RFI shielding plug 3476 = Straight plug
Finish A = Black anodized L = Electroless nickel plating W = Olive drab cadmium plating S = Stainless steel passivated B = Olive green cadmium plating
Shell size 08, 10, 12, 14, 16, 18, 20, 22, 24
Contact layout (see next page)
Contact P = Pin S = Socket PL = PCB pin SL = PCB socket
Orientation N, W, X, Y, Z

Product showing.
MS26482 Connector, MS3476W18-32S, MIL-C-26482Ⅱ, MS26482 SeriesⅡ

Shell size.

Shell No.	D1	D2
08	19.7	0.5000-20
10	23.5	0.6250-24
12	27.0	0.7500-20
14	30.5	0.8750-20
16	34.0	1.0000-20
18	35.3	1.0625-18
20	39.3	1.1875-18
22	43.0	1.3125-18
24	46.0	1.4375-18

Contact.

Contact NO.	Diameter (mm)	Cross section area of cable (mm²)	Resistance (mΩ)	Current (A)
20#	Φ 1.00	0.20	≤ 5	3.0
		0.30		5.0
		0.50		7.5
16#	Φ 1.59	0.50	≤ 3	7.5
		0.80		10.0
		1.25		13.0
12#	Φ 2.39	2.00	≤ 2	17.0
		3.15		23.0

Straight plug (MS3475/MS3476)

MS26482 Connector, MS3476W18-32S, MIL-C-26482Ⅱ, MS26482 SeriesⅡ

Contact layout

MS26482 Connector, MS3476W18-32S, MIL-C-26482Ⅱ, MS26482 SeriesⅡ
